HSD ES327 - Page 79

6 Operation and regulation
HSD S.p.A. © - 0106h03a.fm100713
79
ES331
DIAGRAM SETTING SENSORS
TOOL OUT
TOOL IN
TOOL IN
WITHOUT TOOL
0.3
+0
-0.10
0.5
+0
-0.10
0.7
+0
-0.10
S2
S4
S3
CONDITIONS
WITHOUT TOOL
TOOL IN
TOOL OUT
S2
OFF ON ON
OFF OFF ON
ON OFF OFF
S3 S4 S2 S3 S4
BROWN +
BLU -
BLACK
0V
UB10-30V
PNP NO
