6 Operation and regulation
80
HSD S.p.A. © - 0106h03a.fm100713
ES332
ES370
STATE S1 S2 S1+S4 S5
Collet open
(tool holder cone ejected)
OFF ON OFF OFF
Tool holder cone
coupled
ON OFF ON ON
Collet closed but
with no tool holder cone
OFF OFF OFF ON
STATE S1 S1+S4
Tool holder cone coupled but not
in contact with the HSK surface
ON OFF
Tool holder cone
coupled
ON OFF
Tool holder cone missing OFF OFF
Tool holder cone
locked correctly
ON ON
The electrospindle shaft can only rotate in the "tool holder cone locked
correctly" state; if S1 or S1 + S4 output changes to “OFF”, stop the rotation of
the electrospindle shaft.
