HSD SM 141 D User Manual

3 Main parts
24
HSD S.p.A. © - h0102k02a.fm091115
3.2 SM 141 D General overview and main parts
A- Motor; it allows the machine parts to move. It is fitted on a lot of devices thanks to its 230 Vac
(50/60Hz) power supply. The rotation is controlled electronically. The shaft outfeed flange
(bracketing flange) is fitted with special holes to be fastened to the device.
B- Motor shaft ; transmits the motion to the device.
C- Connection panel; side of the electronic drive on which the electrical connections are located.
D- Support flange; the support flange is fitted with holes to bracket the equipment onto the
device or the user machine.
E- Electronic drive ; to manage the motor rotation .
F- Dip-switches; for configuration settings.
B
D
A
E
E
F
C
