HSD SM 141 D User Manual

A Technical characteristics
HSD S.p.A. © - h0124k00a.fm091115
57
A Technical characteristics
The following table shows the product technical data.
A.1 General data
ELECTRICAL AND MECHANICAL CHARACTERISTICS 350W 450W
Power supply (S1 continuous service conditions) unit SM 141 - CPH 400
Rated current A
RMS
3.5 4.5
Absorbed power W 410 530
Rated voltage (±10% single-phase) V
RMS
230
Mains frequency (±4%) Hz 50-60
Power factor 0,51
Brake recovery and dissipation unit SM 141 - CPH 400
Energy recovery for each stoppage without dissipation J 27
Dynamic brake mean power W20
Logic power unit SM 141 - CPH 400
Logic power supply (P24V)
Safety power origin ±10% (SELV or PELV)
V
DC
24
Logic max. electric current requirement (P24V) without brake mA 300
Logic max. electric current requirement (P24V) with brake mA 700
Encoder input unit SM 141
Encoder type: incremental
pulses/
rotation
2048
Encoder input unit CPH 400
Encoder type: incremental/absolute, 5/24V, push-pull/open
collector/line driver RS422
f
max
kHz
500
Input/Output unit SM 141 - CPH 400
Numeric inputs n 4
Numeric inputs types
for restoring, positive/negative
overstroke, tracing
Manual setting 2 8-limitswitches dip-switches
Communication Bus SM 141 - CPH 400
Types of Bus E-NETx
