HSD SM 141 D User Manual

3 Main parts
HSD S.p.A. © - h0102k02a.fm091115
27
3.6 Identification of the manufacturer and of the product
The name and address of the manufacturer are:
HSD S.p.A.
main headquarters: Via Pesaro, 10A - 61012 Gradara (PU) ITALY
registered offices: Via della Meccanica, 16 - 61122 Pesaro ITALY
The manufacturer and the product are identified by the I.D plate on the electronic drive body.
The plate contains the information listed below.
A - logo and address of
manufacturer, product
name
B - operational service
C - product IP code (protection
class)
D - maximum torque
E - nominal torque
F - nominal power
(at the shaft in S1)
G - maximum speed
H - nominal speed
I - expected short-circuits
(nominal value)
L - power supply frequency
M - nominal power supply
current
N - logic power supply voltage
O - nominal power supply
voltage
P - serial number
Q - product code and revision
number
R - danger of electrocution sign
S - functional earth connection
sign
T - hot surfaces danger signs
U - read instructions sign
V - CE marking
W - nominal branch voltage
Z - nominal inverter current
SM 141
CPH 400
bar code
IEC 60034-1
SM 141
Via della Meccanica,16
61122 - PESARO
HSD
SCCR 1,5 kA
f
LN
50 Hz
N
Max
5000 rpm
P
N
450W@3000rpm
M
N
1,43Nm@3000rpm
M
Max
4,17 Nm
IP rating 54
N
0
3000 rpm
Service class S1
I
LN
4,5 ARMS
ACU
LN
230 V -TN /S
1ph+N/PE-2ph/PE
DCU
Log
24V PELV / SELV
A
B
C
D
E
F
G
H
I
L
M
N
O
U
CPH 400
IEC 60034-1
Via della Meccanica,16
61122 - PESARO
HSD
SCCR 1,5 kA
U
LN
U
I
LN
Log
f
LN
U
aN1
I
aN1
4,5 A
50 Hz
2,4 A
RMS
IP rating 65
78 V
RMS
DC
AC230 V -TN /S
1ph+N/PE-2ph/PE
24V PELV / SELV
A
C
Z
I
L
M
N
O
W
U
V
Q
P
R S T
V
