HT 63 - Page 49

HT63
EN - 20
Resistance and Continuity test
Range Resolution Accuracy Buzzer
Protection against
overcharge
600.0 0.1 (2.0%rdg + 9digits)
<35
1000VDC/ACrms
6.000k 0.001k
(1.2%rdg + 5digits)
60.00k 0.01k
600.0k 0.1k
6.000M 0.001M
(2.0%rdg + 10digits)
60.00M 0.01M
Frequency (electronic circuits)
Range Resolution Accuracy
Protection against
overcharge
40.00Hz  10kHz
0.01Hz
(0.5%reading)
1000VDC/ACrms
Sensitivity: 15Vrms
Frequency (electronic circuits)
Range Resolution Accuracy
Protection against
overcharge
60.00Hz 0.01Hz
(1.0%rdg + 2digits)
1000VDC/ACrms
600.0Hz 0.1Hz
6.000kHz 0.001kHz
60.00kHz 0.01kHz
600.0kHz 0.1kHz
6.000MHz 0.001MHz
10.00MHz 0.01MHz
Sensitivity: >2.0Vrms (@ 20%  80% duty cycle) and f<100kHz; >5Vrms (@ 20%  80% duty cycle) and f>100kHz
Duty Cycle
Range Resolution Accuracy
0.1%  99.9%
0.1%
(1.2%reading + 2digits)
Pulse frequency range: 5Hz  10kHz, Pulse amplitude: ±5V (100s  100ms)
Capacity
Range Resolution Accuracy Protection against overcharge
60.00nF 0.01nF
(3.5%rdg + 10digits)
1000VDC/ACrms
600.0nF 0.1nF
6,000F 0,001F
(2.5%rdg + 10digits)
60.00F 0.01F
600.0F 0.1F
6.000mF 0.001mF
(3.5%rdg + 10digits)
Temperature with K-type probe
Range Resolution Accuracy (*)
Protection against
overcharge
-40.0°C ÷ 600.0°C 0.1°C
(2.0%rdg + 3°C)
1000VDC/ACrms
600°C ÷ 760°C 1°C
-58.0°F ÷ 600.0°F 0.1°F
(2.0%rdg+ 5.5°F)
600°F ÷ 1400°F 1°F
(*) Instrument accuracy with no probe
