Figure 14-2 Add/Edit GRE Tunnel
The following table describes the fields in this screen.
Table 14-2
Add/Edit GRE Tunnel
Label Description
GRE Setup
Enabled Select this to have the LTE Device use the GRE tunnel.
Clear it to configure the GRE tunnel but not use it.
Tunnel Name Enter a descriptive name for the GRE tunnel.
GRE Layer Select which OSI layer (Layer2 GRE or Layer3 GRE) protocol the
GRE tunnels over a network. Use layer 2 when both of the LAN PC
IPs are in the same subnet domain. Use layer 3 when the LAN PC IPs
are in dif
ferent subnet domains.
Server IP
Address
Enter the IP address or domain name of the remote gateway to which
the LTE Device's W
AN interface tunnels traffic.
GRE Local IP Enter a local host's IP address the LTE Device tunnels the traffic sent
to the remote gateway.
