Installation Manual -Antenna & Feeder System Installation
BTS3802C & RRU Chapter 1 Installation Preparations
1-5
Figure 1-1 Simple protection treatment of a feeder connector
î Note:
z The connectors of the indoor jumpers (1/2â, 7/16 DIN, male) are normally added after the feeders are
led into the room.
z The jumpers are adopted in fixed length are adopted as the outdoor jumpers. There is no need to
add their connectors onsite, since they have all been added before delivery. If it is necessary to add
them onsite, please follow the instructions in their packing boxes.
Caution:
If the connector has not been added to the feeder or the connector has been add to the feeder but the
feeder has not been connected with the jumper, and the remaining operation needs to be done on the
next day, then apply simple water treatment to connecting point of the feeder by wrapping up the
connecting point with waterproof tape, as shown in Figure 1-2, or covering the connecting point with a
plastic bag and then wrapping it up with waterproof tape.
