FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
Figure 2-3 Floor plan of the single-row 1200 mm wide aisle containment (power supply and
distribution cabinet)
The PDC refers to the precision PDC or integrated UPS cabinet.
Table 2-1 lists the key technical specifications of the single-row 1200 mm wide aisle
containment.
Table 2-1 Key technical specifications
⚫
In the scenario where the new main way is deployed, the minimum
floor height is 3.0 m when 2.0 m high IT cabinets are deployed and
is 3.2 m high when 2.2 m high IT cabinets are deployed.
⚫
In the scenario where the new main way is not deployed, the
minimum floor height is 2.6 m when 2.0 m high IT cabinets are
deployed and is 2.8 m high when 2.2 m high IT cabinets are
deployed.
NetCol5000-C 30 kW chilled water in-row precision air conditioner
⚫
Smart module A: integrated UPS cabinet
⚫
Smart module B: precision PDC or new main way
1200 mm wide single-row cold or hot aisle containment
