Huawei FusionModule5000 Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
16
Name
Dimensions (H x W x D)
Applicable Cabinet
Dimensions (H x W x D)
300 mm wide
flat skylight
341 mm x 305 mm x 1334 mm
⚫
2000 mm x 300 mm x 1200
mm
⚫
2000 mm x 300 mm x 1100
mm
⚫
2200 mm x 300 mm x 1200
mm
600 mm wide
flat or rotating
skylight
341 mm x 605 mm x 1334 mm
⚫
2000 mm x 600 mm x 1200
mm
⚫
2000 mm x 600 mm x 1100
mm
⚫
2200 mm x 600 mm x 1200
mm
800 mm wide
flat or rotating
skylight
341 mm x 805 mm x 1334 mm
⚫
2000 mm x 800 mm x 1200
mm
⚫
2000 mm x 800 mm x 1100
mm
⚫
2200 mm x 800 mm x 1200
mm
Figure 3-6, Figure 3-7, Figure 3-8, and Figure 3-9 show the skylights.
Figure 3-6 300 mm wide skylight
(1) Skylight connective plate
(2) Flat skylight panel
