Huawei FusionModule5000 Product Description

FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
37
Figure 3-26 Battery cabinet components
(1) BIB
(2) CIM
(3) Batteries
(4) Circuit breaker
Table 3-11 lists the technical specifications of a battery cabinet.
Table 3-11 Battery cabinet technical specifications
Parameter
Specifications
Dimensions (H x W x D)
⚫
Basic dimensions: 2000 mm x 600 mm x 1100 mm
⚫
Basic dimensions: 2000 mm x 600 mm x 1200 mm
⚫
Dimensions after expansion: 2200 mm x 600 mm x 1200
mm (with the top frame)
Color
Black
Materials
The materials are high-intensity class A carbon cold rolled
steel sheet and zinc-coated steel sheet.
Ventilation channel
Front and rear ventilation channels
Installation space
Provides 42 U space
Installation mode
ESD floor or concrete floor
