FusionModule5000 Smart Modular Data Center
Product Description (ECC800)
Table 3-54 Specifications of a card reader with a password keyboard
Range: 10.8–13.2 V DC, rated voltage: 12 V DC
Static standby current 80 mA, operating current during
card swiping and button pressing 150 mA, minimum input
current 300 mA at 12 V DC
Magnetic Double-door Lock
Figure 3-58 shows a magnetic double-door lock.
Figure 3-58 Revolving door magnetic lock
Figure 3-59 Sliding door magnetic lock
⚫
The access control system applies to the equipment room, aisle containment, and cabinet
doors.
