2 Solut
ion Overview
The PV+ESS+Charger Solution integrates the PV system and energy storage system
(ESS) with a char
ger to charge vehicles, which also helps save electricity costs
through peak and o-peak electricity price dierences. The charger implements
dynamic charging power based on the power information delivered by the
management system and the grid-connection point power information reported
by the meter. The solution includes the inverter, ESS, optimizer, AC charger, meter,
management system, and FusionSolar app.
Product Introduction
Table 2-1 Product list
Component Model Description
Inverter SUN2000-(2KTL-6KTL)-L1
SUN2000-(5KTL-12KTL)-M1
SUN2000-(8KTL-20KTL)-M2
● When an inverter is
congured, PV power
can be used for
charging vehicles.
ESS LUNA2000-(5-30)-S0 ● 5 kWh per battery
module, system
capacity up to 30 kWh
when two ESSs are
cascaded
AC charger SCharger-7KS-S0 (single-
phase)
SCharger-22KT-S0 (three-
phase)
● Multiple charging
modes are available.
Backup Box Backup Box-B0 (single-phase)
Backup Box-B1 (three-phase)
● On/O-grid scenarios
are supported.
