Huawei SmartAX MA5600T Hardware Description

DIP Switch Indication Default Settings
S1-3
l ON: The address bit is 0.
l OFF: The address bit is 1.
By default, the address bit is 1.
ON
S1-4 ON The baud rate of the
communication between the fan
tray and the control board is 19200
bit/s.
ON
OFF The baud rate of the
communication between the fan
tray and the control board is 9600
bit/s.
S1-5 It is used to set the scenario of fans. The
high eight dip switch should be 0000 0000
for MA5603T subrack.
l 0 indicates the switch should be ON.
l 1 indicates the switch should be OFF.
ON
S1-6 ON
S1-7 ON
S1-8 ON
SW1-1 ON
SW1-2 ON
SW1-3 ON
SW1-4 ON
Table 2-40 describes the settings of the low three DIP switches of S1.
Table 2-40 Settings of S1-1, S1-2, and S1-3
S1-3
S1-2 S1-1 Address Value
ON ON ON 0
ON ON OFF 1
ON OFF ON 2
ON OFF OFF 3
OFF ON ON 4
OFF ON OFF 5
OFF OFF ON 6
OFF OFF OFF 7
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
2 Subrack and Chassis
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
126
