Figure 3-90 Position of the daughter board on the H801ASPB board
Table 3-60 describes the daughter board supported by the H801ASPB board.
Table 3-60 Daughter board supported by the H801ASPB board
Daughter Board
Function Remarks
H806ASDB Supports the VoIP function. Mandatory
Pin Assignments
For pin assignment of the LINE0 port, see Table 3-61; For pin assignment of the LINE1 port,
see Table 3-62;
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
470
