Huawei SmartAX MA5600T Hardware Description

Port Pin Signal Remarks
6 PPS0_IN+ Positive polarity of channel 0
PPS time signals
7 - -
8 GND Grounding
Table 3-159 Pin assignments of the BITS/TOD IN1 port
Port
Pin Signal Remarks
1
2
3
4
5
6
7
8
1 BITS1_IN_B Input B of channel 1 BITS
clock signals
2 BITS1_IN_A Input A of channel 1 BITS
clock signals
3 PPS1_IN- Negative polarity of channel 1
PPS time signals
4 TOD1_IN- Negative polarity of channel 1
TOD time signals
5 TOD1_IN+ Positive polarity of channel 1
TOD time signals
6 PPS1_IN+ Positive polarity of channel 1
PPS time signals
7 - -
8 GND Grounding
Table 3-160 Pin assignments of the BITS OUT port
Port
Pin Signal Remarks
1
2
3
4
5
6
7
8
1 TOD_OUT- Negative polarity of the TOD
time signals output
2 TOD_OUT+ Positive polarity of the TOD
time signals output
3 PPS_OUT- Negative polarity of the PPS
time signals output
4 BITS_OUT_B Output B of the BITS clock
signals
5 BITS_OUT_A Output A of the BITS clock
signals
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
738
