NOTICE
l When cables from the PSTN and LINE ports are routed to an outdoor environment, the
MDF must be installed with a protective unit.
l When cables from the LINE port are routed to the user side, the MDF must be installed
with a protective unit.
l The PSTN port must be connected to an MDF with a protective unit or a POTS device.
Otherwise, when the LINE port is struck by lightning, energy inside the SPL board or unit
fluctuates and overlaps, which may damage the LINE port.
Port
The ports of the H801VSPLA board are located on its front panel. Table 3-219 describes the
ports of the H801VSPLA board.
Table 3-219 Ports of the H801VSPLA board
Port
Function Connection
xDSL1 Provides 32 channels (channels
32-63) of VDSL2 access
service.
Use an intra-subrack interconnection
cable or inter-subrack interconnection
cable to connect the port to an xDSL port of
the VDSL2 service board.
xDSL0 Provides 32 channels (channels
0-31) of VDSL2 access
service.
LINE0 Provides 32 channels (channels
0-31) of user access service.
Use a subscriber cable to connect the port
to the MDF.
LINE1 Provides 32 channels (channels
32-63) of user access service.
PSTN0 Provides 32 channels (channels
0-31) of POTS access service.
Use a subscriber cable to connect the port
to the MDF.
PSTN1 Provides 32 channels (channels
32-63) of POTS access service.
NOTICE
l When cables from the PSTN and LINE ports are routed to an outdoor environment, the
MDF must be installed with a protective unit.
l When cables from the LINE port are routed to the user side, the MDF must be installed
with a protective unit.
l The PSTN port must be connected to an MDF with a protective unit or a POTS device.
Otherwise, when the LINE port is struck by lightning, energy inside the SPL board or unit
fluctuates and overlaps, which may damage the LINE port.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
3 Board
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
827
