Huawei SmartAX MA5600T Hardware Description

Operating
Wavelength
Tx: 1577 nm
Rx: 1270 nm
Tx: 1577 nm
Rx: 1270 nm
Tx: 1577nm
Rx: 1270nm
Encapsulatio
n Type
XFP SFP+ SFP+
Port Rate Tx: 9.953 Gbit/s
Rx: 2.488 Gbit/s
Tx: 9.953 Gbit/s
Rx: 2.488 Gbit/s
Tx: 9.953 Gbit/s
Rx: 2.488 Gbit/s
Minimum
Output
Optical
Power
2 dBm 2 dBm 4dBm
Maximum
Output
Optical
Power
6 dBm 6 dBm 8dBm
Maximum
Receiver
Sensitivity
-27.5 dBm -27.5 dBm -29.5dBm
Optical
Connector
Type
SC SC SC
Optical Fiber
Type
Single-mode Single-mode Single-mode
Overload
Optical
Power
-7 dBm -7 dBm -9dBm
Extinction
Ratio
8.2 dB 8.2 dB 8.2dB
Standards Compliance of the GPON Port
Standard ID
Description
ITU-T G.984.1 Gigabit-capable Passive Optical Networks (GPON)
General Characteristics
ITU-T G.984.2 Gigabit-capable Passive Optical Networks (GPON)
Physical Media Dependent (PMD) Layer Specification
ITU-T G.984.3 Gigabit-capable Passive Optical Networks (GPON)
Transmission Convergence Layer Specification
ITU-T G.984.4 Gigabit-capable Passive Optical Networks (GPON) ONU
Management and Control Interface Specification
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
848
