GPON Optical Module
A GPON optical module is connected to one SC optical fiber to provide GPON access
service.
No. 1 2 3
Type One-fiber bi-directional
optical module, class B+
One-fiber bi-directional
optical module, class C+
One-fiber bi-directional
optical module, class C++
Operating
Wavelength
Tx: 1490 nm
Rx: 1310 nm
Tx: 1490 nm
Rx: 1310 nm
Tx: 1490 nm
Rx: 1310 nm
Encapsulation
Type
SFP SFP SFP
Port Rate Tx: 2.488 Gbit/s
Rx: 1.244 Gbit/s
Tx: 2.488 Gbit/s
Rx: 1.244 Gbit/s
Tx: 2.488 Gbit/s
Rx: 1.244 Gbit/s
Minimum
Output Optical
Power
1.50 dBm 3.00 dBm 6.00 dBm
Maximum
Output Optical
Power
5.00 dBm 7.00 dBm 10.00 dBm
Maximum
Receiver
Sensitivity
-28.00 dBm -32.00 dBm -35.00 dBm
Optical
Connector
Type
SC SC SC
Optical Fiber
Type
Single-mode Single-mode Single-mode
Overload
Optical Power
-8.0 dBm -12.0 dBm -15.0 dBm
Extinction
Ratio
10 dB 8.2 dB 8.2 dB
10G GPON Optical Module
A 10G GPON optical module is connected to one SC optical fiber to provide 10G GPON
access service.
No.
1 2 3
Type One-fiber bi-directional
optical module, N1
One-fiber bi-directional
optical module, N1
One-fiber bi-directional
optical module, N2a
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
847
