Huawei SmartAX MA5600T Hardware Description

Table 4-3 Relation between PON optical modules and boards
Board Type Board Name Optical Module
Type
Encapsulation
Type
Port Rate
Upstream
interface board
P2CA GPON Upstream
Optical Module
SFP Tx: 2.49 Gbit/s
Rx: 1.24 Gbit/s
GPON interface
board
GPBC/GPBD/
GPFD/GPBH/
GPMD
GPON Optical
Module
SFP Tx: 2.488 Gbit/s
Rx: 1.244 Gbit/s
10G GPON
interface board
XGBC/XGBD 10G GPON Optical
Module
SFP+ Tx: 9.953 Gbit/s
Rx: 2.488 Gbit/s
GPON Upstream Optical Module
A GPON upstream optical module is connected to one SC optical fiber to provide GPON
upstream transmission.
Type One-fiber bi-directional optical
module, ONU class B+
One-fiber bi-directional optical
module, ONU class C+
Operating
Wavelengt
h
Tx: 1310 nm
Rx: 1490 nm
Tx: 1310 nm
Rx: 1490 nm
Encapsulat
ion Type
SFP SFP
Port Rate Tx: 1.24 Gbit/s
Rx: 2.49 Gbit/s
Tx: 1.24 Gbit/s
Rx: 2.49 Gbit/s
Minimum
Output
Optical
Power
0.50 dBm 0.50 dBm
Maximum
Output
Optical
Power
5.00 dBm 5.00 dBm
Maximum
Receiver
Sensitivity
-27.00 dBm -30.00 dBm (FEC enabled)
Optical
Connector
Type
SC SC
Optical
Fiber Type
Single-mode Single-mode
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
4 Optical and Electrical Module
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
846
