Huawei SmartAX MA5600T Hardware Description

DIP Switch Indication Default Settings
S6-8 S6-8 is used to set the baud
rate of the communication
between the ESCA board
and the control board.
l ON: The baud rate of the
communication between
the ESCA board and the
control board is 19200
bit/s.
l OFF: The baud rate of
the communication
between the ESCA board
and the control board is
9600 bit/s.
ON
Table 6-7 shows the mapping of S5 and ports for sensors.
Table 6-7 Mapping of S5 and ports for sensors
DIP Switch
OFF ON
S5-1 The external sensor of JTA1 is of the
voltage type.
The external sensor of
JTA1 is of the current type.
S5-2 The external sensor of JTA2 is of the
voltage type.
The external sensor of
JTA2 is of the current type.
S5-3 The external sensor of JTA3 is of the
voltage type.
The external sensor of
JTA3 is of the current type.
S5-4 The external sensor of JTA4 is of the
voltage type.
The external sensor of
JTA4 is of the current type.
S6-1 to S6-5 are used to set the subnode addresses of the ESCA board. For details, see Table
6-8.
Table 6-8 Mapping of S6-1 to S6-5 and the subnode address
DIP Switch Settings (5, 4, 3,
2, 1)
Addres
s Value
DIP Switch Settings (5, 4, 3,
2, 1)
Addres
s Value
00000 0 10000 16
00001 1 10001 17
00010 2 10010 18
00011 3 10011 19
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Hardware Description
6 Electromechanical Device
Issue 24 (2018-07-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
917
