Huawei SUN2000-90KTL Series User Manual

Label Name Meaning
Operation
warning
Do not remove the DC
input connector when the
SUN2000 is running.
High voltage
warning
High voltage exists after
the SUN2000 is powered
on. Read this document
carefully before operating
the SUN2000.
DC terminal
operation
warning
High voltage exists after
the SUN2000 is powered
on. To avoid electric
shocks, perform the
following system power-
o operations before
plugging or unplugging
DC input connectors of
the SUN2000:
1. Send a shutdown
command.
2. Turn
o the
downstream AC
switch.
3. Turn o the two DC
switches at the
bottom.
SUN2000 SN
label
Indicates the SUN2000
serial number.
Weight label The SUN2000 needs to be
carried by four persons or
using a pallet truck.
2.4 Working Principles
2.4.1 Circuit Diagram
The SUN2000 receives inputs from 12 PV strings. The inputs are grouped into 6
MPPT circuits inside the SUN2000 to track the maximum power point of the PV
strings. The DC power is then converted into three-phase AC power through an
inverter circuit. Surge protection is supported on both the DC and AC sides.
SUN2000-(90KTL, 95KTL, 100KTL, 105KTL) Series
User Manual
2 Overview
Issue 11 (2020-08-30) Copyright © Huawei Technologies Co., Ltd. 19
