For ease of installing the SUN2000 on the mounting bracket, connecting cables to the
bottom of the SUN2000, and maintaining the SUN2000 in future, it is recommended that
the bottom space be from 600 mm to 730 mm. If you have any question about the
distance, consult the local technical support engineers.
When installing multiple SUN2000s, install them in horizontal mode if sucient
space is available and install them in staggered mode if no sucient space is
available. Stacked installation is not recommended.
Figure 4-5 Horizontal installation mode (recommended)
Figure 4-6 Staggered installation mode (recommended)
SUN2000-(90KTL, 95KTL, 100KTL, 105KTL) Series
User Manual
4 Installation
Issue 11 (2020-08-30) Copyright © Huawei Technologies Co., Ltd. 31
