Huawei SUN2000 M0 Series User Manual

LED Color Status Remarks Description
Yellow (blinking
green and red
simultaneously)
Steady on Normal The Dongle is secured and
powered on.
Green Blinking in a 2-second
cycle (on for 0.1s and
then o for 1.9s)
Normal Dialing (duration < 1 min).
Abnormal If the duration is longer
than 1 min, the 4G
parameter settings are
incorrect. Reset
theparameters.
Blinking at long intervals
(on for 1s and then o
for 1s)
Normal The dial-up connection is set
up successfully (duration <
30s).
Abnormal If the duration is longer
than 30s, the settings of the
management system
parameters are incorrect.
Reset the parameters.
Steady on Normal Successfully connected to
the management system.
Blinking at short
intervals (on for 0.2s and
then o for 0.2s)
The inverter is
communicating with the
management system
through the Dongle.
Red Steady on Abnormal The Dongle is faulty.
Replace Dongle.
Blinking at short
intervals (on for 0.2s and
then o for 0.2s)
The Dongle has no SIM card
or the SIM card is in poor
contact. Check whether the
SIM card has been installed
or is in good contact. If not,
install the SIM card or
remove and insert the SIM
card.
SUN2000-(3KTL-10KTL)-M0
User Manual 6 Commissioning
Issue 06 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 59

Huawei SUN2000 M0 Series Specifications

General

Rated AC Output Power	3000W
European Efficiency	96.7%/97%/97%/97.3%/97.5%/97.8%
Communication	RS485, Wi-Fi
Protection Degree	IP65
Weight	17 kg
Dimensions	440 x 650 x 220 mm
Max. efficiency	98.6%
MPPT voltage range	200-1000V
No. of MPPTs	2
Operating temperature range	-25°C to +60°C
Cooling method	Natural convection
Protection rating	IP65
AC output voltage	230V
