Rear View
Figure 2-5 Rear view
(1) Mounting plate
(2) Mounting bracket
(3) Heat sink
Bottom View
Figure 2-6 Bottom view
No.
Component
Silk Screen
1
DC switch
DC SWITCH
2
DC input terminals
PV+/PV–
3
RS485 port
COM
