5.1 Preparing Cables
Figure 5-1 Network diagram

indicates the power flow direction, and indicates a signal cable.

A maximum of 12 SUN2000L-4.125KTL-JP can be cascaded, and a maximum of 10
SUN2000L-4.95KTL-JP can be cascaded.
(A) PV string
(B) SUN2000L
(C) AC combiner box
(D) Low-voltage power grid
Figure 5-2 Cable connections
