Huawei SUN2000L Series User Manual

SUN2000L-(4.125KTL, 4.95KTL)-JP
User Manual
7 Operations on the Local FusionHome App
Issue 03 (2018-04-11)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
67
7 Operations on the Local FusionHome App
7.1 App Overview
Function
The local FusionHome app (app for short) is a mobile phone app that locally communicates
with the SUN2000L over WiFi to allow for querying alarms, configuring parameters, and
performing routine maintenance, and commissioning.
Connection Method
After the DC or AC side of the SUN2000L is energized, the app can connect to the
SUN2000L in either of the following ways:

Method 1: The mobile phone connects to the SUN2000L directly.
Figure 7-1 Mobile phone connecting to the SUN2000L directly

Method 2: The mobile phone connects to the SUN2000L over a router. Do not use this
method for the first login and ensure that the SUN2000L has connected to the router.
Figure 7-2 Mobile phone connecting to the SUN2000L over a router

Huawei SUN2000L Series Specifications

General

Max. DC Voltage	600 V
Max. Efficiency	98.6%
Cooling	Natural Convection
Protection Degree	IP65
Power Output Range	2kW - 5kW
Max. AC Power	5, 500 VA
Rated AC Voltage	220 V / 230 V
European Efficiency	98.2%
Operating Temperature Range	-25°C to +60°C
Weight	10.6 kg
Communication	RS485
