221
Humminbird Network Setup
3
|
Select GPS Sources (optional)
The ONIX control head defaults to the internal GPS receiver as the primary source (GPS [1]). If you connect an external GPS receiver
to the control head, it will be assigned as the secondary source GPS (2).
If you connect an external GPS receiver to the ION control head, it will be assigned as the primary source GPS (1).
GPS (1) provides position data, Speed over Ground (SOG), Course over Ground (COG), waypoints, routes, tracks, and navigation
calculations to the control head.
GPS (2) provides position data that is displayed in the GPS (2) data box.
You can also manually change which GPS receiver is the selected source for GPS (1) or GPS (2). For example, if you’ve connected
an external GPS receiver to the ONIX control head, you can assign it to GPS (1), so the control head will use it as the primary source
(instead of the internal GPS receiver). If the control head is part of an Ethernet or NMEA 2000 network, you can also select the GPS
receivers from the network.
Open the GPS Tool
1. Press the HOME key.
2. Select the GPS tool.
Select GPS Sources Automatically
1. Under GPS Source, select GPS (1) or GPS (2).
2. Select Auto-Configure. Tap the on/off button, or press the ENTER key, to turn it on.
Select GPS Sources Manually
Use the instructions in this section to manually select a GPS source.
1. Under GPS Source, select GPS (1) or GPS (2).
2. Select Auto-Configure. Tap the on/off button, or press the ENTER key, to turn it off.
3. Select a GPS receiver from the list.
Share GPS Sources with the Network
1. Under GPS Source, select Global Source.
2. Tap the on/off button, or press the ENTER key, to turn it on.
NOTE: See Set up your Humminbird Network for details about Global On/Off.
