Specications
Specications
OPERATING SPECIFICATIONS
• Number of Stations: Modular design expandable from
8 to 38 (plastic), 8 to 54 (metal)
• Station Run Time: 1 minute up to 12 hours
• Start Times: 8 per program, 4 independent
programs (A, B, C, and D)
• Simultaneous Program Operation: 2
• Sensor Inputs: 1
• Pump/Master Valve Outputs: 1
• Watering Schedule: 7-day calendar, interval watering up
to a 31-day interval or true odd or even day programming
DIMENSIONS
PLASTIC CABINET
• Height: 12" (30.5 cm)
• Width: 13.7" (34.8 cm)
• Depth: 5" (12.7 cm)
METAL CABINET GRAY OR SS
• Height: 16" (40.6 cm)
• Width: 13" (33 cm)
• Depth: 5" (12.7 cm)
METAL PEDESTAL GRAY OR SS
• Height: 36" (91.4 cm)
• Width: 11.5" (29.2 cm)
• Depth: 5" (12.7 cm)
PLASTIC PEDESTAL
• Height: 39" (99.1 cm)
• Width: 24" (61 cm)
• Depth: 17" (43.2 cm)
ELECTRICAL SPECIFICATIONS
• Transformer Input: 120 VAC, 60 Hz
(230 VAC, 50/60 Hz international use)
• Transformer Output: 24 VAC, 1.4 A
• Station Output: 24 VAC, up to 0.56 A
• Pump/Master Valve Output: 24 VAC, up to 0.56 A
• Battery: 9-volt alkaline battery (not included) used only
for non-AC programming; non-volatile memory maintains
program information
• Front Panel Battery: Internal CR2032 lithium (included)
for real-time clock
APPROVALS
• CE, UL, cUL, FCC, RCM
• Plastic Cabinet: IP44, NEMA 3R
• Metal Cabinet (Gray or SS): IP44, NEMA 3R
• Metal Pedestal (Gray or SS): IP44, NEMA 3R
• Plastic Pedestal: IP24, NEMA 3R
DEFAULT SETTINGS
• All stations are set to zero run time. This controller has a
non-volatile memory that retains all entered program data
even during power outages, without the need for a battery.
