Operation Instructions for TCX50 Tire Charger
14
Make sure that the electrical supply circuit and the appropriate receptacle is installed with
proper grounding.
To prevent the possibility of electrical shock injury or damage to the equipment when servicing
the TCX50, power must be disconnected by removing the power cord from the electrical
power outlet.
Specic Precautions/Power Source
The TCX50 is equipped with a double voltage motor, (110VAC/220VAC), set up from the
factory at 220V, please referrer to the installation manual to set a different voltage.
Tire changer is equipped with 110V standard plug and 220V L6-20P plug.
This machine must be connected to a 20 amp branch circuit. Please refer all power source
issues to a certied electrician. Refer to “Installation Instructions for TCX50
Tire Changer,”
Cod. 4-118378 09/13.
WARNING
A protective ground connection, through the grounding conductor in the power
cord, is essential for safe operation. Use only a power cord that is in good condition.
Equipment installation and service
A factory-authorized representative should perform installation.
This equipment contains no user serviceable parts. All repairs must be referred to a qualied
Hunter Service Representative
Equipment specication
Electrical
Voltage:
208-230 VAC, 1 phase, 60 Hz, includes NEMA L6-20P
or
110-115 VAC, 1 phase, 60 Hz, includes NEMA 5-15P
Circuit size: 20 amps
Air
Air Pressure Requirements: 115-175 PSI (7.9-12.0 bar)
Approximate Air
Consumption:
at 8 bar = 6 Lt/s • 0.2118 Ft3/s • 12,70 CFM (ft3/min)
at 10 bar = 7,76 Lt/s • 0.2471 Ft3/s • 14,82 CFM (ft3/min)
Mechanical
Clamping System Rotating
Speed:
CW – 10 rpm
CCW – 10 rpm
Max. Tire Diameter: 50 in.
Max Bead Roller Opening
Width:
15 in.
Diameter Range: 10-28
Explanations of symbols
These symbols may appear on the equipment.
Alternating current.
Earth ground terminal.
