Installation
5
Mounting Depth Requirements
Power Option
Minimum
Mounting Depth
Inside Mount
Minimum
Mounting Depth
End Mount
Minimum
Fully Recessed
Mounting Depth
High Mount
Battery Wand
1" 1
3
/
4
" 2
3
/
4
"
Low Mount
Battery Wand
1" 1
3
/
4
" 2
5
/
8
"
All Other
Power Options
1
/
2
" 1
1
/
4
" 2
1
/
4
"
■
Drill the screw holes using a
3
/
32
" drill bit.
CAUTION: Use drywall anchors when mounting into drywall.
■
Use a level to check that the mounting surface is level. Shim the brackets if necessary.
■
Attach the installation brackets using the screws provided.
IMPORTANT: The front edges of the installation brackets must be level and aligned. If
mounting to a heavily textured surface, shim the brackets, if needed.
Proceed to “STEP 2 — Install the Shade” on page 9.
See
Chart
Use Center Hole
When Depth Permits
To Next Page
