Hyd-Mech S20A User Manual

8.1
SECTION 8 - SPECIFICATIONS
Rectangular 16" (405mm) high x 20" (505 mm) wide
Round 16" (405mm) dia
Rectangular 16" (405mm) high x 14" (355mm) wide
Round 14" (355mm) dia
Rectangular 16" (405mm) high x 8.5" (205mm) wide
Round 8.5" (205mm) dia
Length 16' 10" +/- .5" (5130mm +/- 13mm)
Width 1 1/4" (32mm)
Thickness 0.042" (1mm)
Blade Tension Manual Min. = 2600 lbs (1180kg) Max. = 3000 lbs (1360kg)
Blade Speed Variable frequency drive 75-350 surface feet/min (23-105 surface m/min)
Blade Guides
Blade Wheel Dia
Variable frequency drive 8.8 HP (6.6 kW)
Hydraulic drive 1.5 HP (1.1 kW)
Hydraulic System
Hydraulic Tank Capacity
Coolant Pump
Coolant Reservoir
Table Height
Shuttle Stroke
Machine Weight
Overall Dimensions
Work Load
Mist lubrication system
Options
Submersible 2E-38NT
Blade
20" (508mm)
102" (2590mm) wide x 95" (2413mm) long x 61" (1550mm) high
78" (1980mm) high with bundling option
9 US Gallons (34 L)
S23A BANDSAW SPECIFICATIONS
Variable vise pressure
Full capacity bundling
5000 lbs (2250kg)
29" (736mm)
4300 lbs (1960 kg) with bundling option
Capacity - 90º
Carbide inserts
33" (838mm)
Motors
4.75 U.S. Gallons (18 L)
Capacity - 45º
Capacity - 30º
500 - 580 psi (35-40 bar)
S23A BANDSAW SPECIFICATIONS

Hyd-Mech S20A Specifications

General

Brand	Hyd-Mech
Model	S20A
Category	Saw
Language	English
