1.6
Tighten SHCS
• Use the leveling foot bolts to raise the infeed base towards the wear plate. Tighten the four socket head cap screws
(390715) to mate the two pieces together. Level the infeed base with the machine by elevating the rear adjusting bolt.
Once level has been achieved make sure that all levelling bolts are touching the oor.
• Remove the infeed base cover. Feed the bundle of hydraulic hosed and electrical cables from inside the machine to
the infeed base
