2.6
STD KERF @ 90° 75° 60° 55° 50° 45° 40° 35° 30°
1 ¼” BLADE .066 .068 .076 .081 .086 .093 .103 .115 .132
1 ½” BLADE .074 .077 .085 .090 .097 .105 .115 .139 .148
KERF CORRECTION FOR ANGLE CUTTING (Manual Mode)
When making mitered cuts, the part length must be set longer than the desired length by an amount called the KERF
CORRECTION or the kerf value must be adjusted. This is due to the fact that the PLC will not account for a dierence in
the kerf value at various angles. If the kerf value is to be adjusted, its value can be accessed by pushing the next button.
To return to previous screen press exit key.
The Standard kerf and corrected values are as follows:
