2.9
PARAMETER DEFINITION
MATERIAL INFEED Defines the infeed side of the machine.
MACHINE TYPE Defines the style of machine.
MACHINE MODEL Defines model.
SHUTTLE CONSTANT Specifies linear distance of shuttle movement in inches per one pulse.
SHUTTLE FULL STROKE Maximum usable shuttle travel.
SHUTTLE SLOW SPEED Minimum shuttle speed constant.
SHUTTLE MAX SPEED Maximum shuttle speed constant.
SHUTTLE
ACCELERATION TIME
Shuttle acceleration time. Time, in milliseconds that the shuttle will accelerate from
0"/s to full speed.
SHUTTLE
DECELERATION TIME
Shuttle deceleration time. Time, in milliseconds that the shuttle will decelerate from full
speed to 0"/s.
SHUTTLE BACKLASH Backlash value of the shuttle drive system.
LENGTH TARGET WINDOW Allowable +/- tolerance from programmed angle.
FRONT VISE OPEN Delay time for the opening of the FRONT VISE in milliseconds.
SHUTTLE VISE OPEN
DWELL
Delay time for the opening of the SHUTTLE VISE in milliseconds.
VISE CLOSE TIME Delay time for the closing of the SHUTTLE or FRONT VISE in milliseconds.
LEFT ANGLE CONSTANT This constant represents LEFT Angle Encoder Resolution.
RIGHT ANGLE CONSTANT This constant represents RIGHT Angle Encoder Resolution.
ANGLE TARGET WINDOW Allowable +/- tolerance from programmed angle.
HEAD SWING ACEL/DECEL
DISTANCE
Acceleration / Deceleration distance.
HEAD SWING MAX. SPEED Head swing maximum speed.
HEAD SWING SOFT (30 DEG L) Head swing soft over travel.
HEAD SWING SOFT (30 DEG R) Head swing soft over travel.
HEAD 90DEG SET Set new 90 deg position.
BP RADIUS The distance in inches from the front side of the blade to the pivot point of the head.
DP RADIUS
The distance in inches from the inside face of the fixed jaw on the front vise (usually
referred to as the datum line) to the pivot point of the head.
FEED RATE CONSTANT
Feed rate display constant value. If the actual feed rate differs from displayed value,
enter new Height Constant=(old Height Constant x actual feed rate)/ displayed fed
rate.
BLADE SPEED CONSTANT
Blade Speed Display adjustment number. If actual blade speed is different than
displayed blade speed, a new Speed Constant will need to be calculated. Speed
Constant = old Speed Constant x actual speed / displayed speed.
BLADE MOTOR FLA Blade motor full load current.
BROKEN PROX
Allows user to override signal from blade drive. Allow to run "dry cycle" in automatic
mode without running the blade. Set to YES allows machine to run auto cycle without
blade running.
MULTI QUEUE Allows the operator to run several jobs (max 10) in series
CONVEYOR SPEED RATIO Allows the conveyor speed to be calibrated to match the shuttle speed.
