HYDAC FILTER SYSTEMS OLF-5 Series - Technical Data

3 | Filter unit/filter housing over-view HYDAC FILTER SYSTEMS GMBH
30 / 100 MoWa OLF-5 3433222d en-us print
3.5 Technical Data
The technical data of the filter unit is as follows:
Bypass opening pressure
for the filter element
≈3.5bar
Permissible fluid contamina-
tion
<12NAS according to ISO4406
Class 23/21/18
Flow rate and
permitted operating pres-
sure
OLF-5-… =5l/min
3.5bar
OLF-5/4 /
OLF-10/4
=5l/min
4.5bar
OLF-5/15 /
OLF-10/15
=15l/min
4.5bar
Permissible viscosity range OLF-5-S =15…150mm²/s
OLF-5/4 /
OLF-10/4
=15…7000mm²/s
OLF-5/15 /
OLF-10/15
=15…1000mm²/s
Permissible pressure at suc-
tion port (IN)
-0.4…0.6bar
Permissible fluid tempera-
ture range
0…80°C / 32…176°F
Permissible ambient tem-
perature range
-20 to 40 °C / -4 to 104 °F
Permitted storage tempera-
ture range
0…50°C / 32…122F
Protection class IP54
Empty weight see type label
Filtration rating ß(2) > 1000 (∆p2.5bar) for the
N5DMxxx or N10DMxxx filter el-
ement
Supply voltage/power con-
sumption
See the name plate on the elec-
tric motor
