5 | Mounting/installing HYDAC FILTER SYSTEMS GMBH
44 / 100 MoWa OLF-5 3433222d en-us print
5 Mounting/installing
The following provides information on how to install and con-
nect the filter unit/filter housing, hydraulically and electrically.
5.1 Fastening/mounting the filter unit
The filter unit must be mounted vertically. Fix the filtration unit
by means of four suitable screws, with the mounting base or
the base on the electric motor, depending on the version.
While doing so, make sure that there is sufficient space below
and above the filter bowl respectively to change the filter ele-
ment.
Fig.13:
Assembly with a mounting base
1
2
3
4
5
6
7
8
A
