3.6.3.1 OLF-5/4-SP…component
The filter unit has the following components:
Fig.11: OLF-5/4-SP… components
Item Description
IN Fluid inlet
OUT Fluid outlet
1.2 Clogging indicator
2.0 Electric motor
2.1 Ventilator hood
2.3 Terminal box
2.4 Mounting base/electric motor base
3.0 Filter cartridge
