HYDAC FILTER SYSTEMS OLF-5 Series - Tab. 15 Differential Pressure Indicator, Electrical VM X D.X; -Lxx

A | Appendix HYDAC FILTER SYSTEMS GMBH
92 / 100 MoWa OLF-5 3433222d en-us print
Response pressure and indi-
cation range respectively
VM2D.x=2bar -10%
VM3D.x=3bar -10%
VM5D.x=5bar -10%
Permissible operating over-
pressure
≤210bar
Permitted temperature range -30…+100°C
Connector threads G½
Installation space required According to HN28-22
Maximum tightening torque 33Nm
Switching type N/C or N/O
(change-over contacts)
Maximum switching voltage /-L24=24VDC
/-L48=48VDC
/-L115=115VAC
/-L230=230VAC
Max. switching voltage at re-
sistive load
60W
100VAAC
Switching capacity ohmic 3A@24VDC
ohmic 0.03to5A@230VAC
Electrical connection Male connection M20
Female connector to
DINEN175301-803
Protection class in accordance
with DIN40050
IP65 (only if the connector is
wired and fitted correctly)
Tab.15: Differential pressure indicator, electrical VMxD.x/-Lxx
