HYDAC FILTER SYSTEMS OLF-5 Series - Spare Parts - Toploader T; TV; Tab. 11 Spare Parts - Toploader T; TV

A | Appendix HYDAC FILTER SYSTEMS GMBH
80 / 100 MoWa OLF-5 3433222d en-us print
A.1.1 Spareparts - Toploader T / TV
The following spare parts are available for the Toploader T /
TV version:
Item Qty Designation Part no.
1.11 1 Drain screw with seal ring G1/4 NBR 617095
1.11 1 Drain screw with seal ring G1/4 FKM 630700
3.20 1 Housing clamp for Toploader 3925239
3.60 1 Filter bowl cover, complete, consisting
of:
- Filter bowl cover with handle
- O-ring
- Drain plug
Alu/FKM 3233899
3.6.2 1 O-Ring for filter housing NBR 615002
3.6.2 1 O-Ring for filter housing FKM 6011252
3.6.3 1 Air bleed screw with seal ring NBR 615002
3.6.3 1 Air bleed screw with seal ring FKM 615003
4.10 1 Dirt catch tray 1202364
- 1 Label for changing the filter element 3232421
- 1 AIR BLEED label 3233901
- 1 DRAIN label 3130552
Tab.11: Spareparts - Toploader T / TV
