HYDAC FILTER SYSTEMS OLF-5 Series - Tab. 14: Differential Pressure Indicator, Electrical VM X C.X

A | Appendix HYDAC FILTER SYSTEMS GMBH
90 / 100 MoWa OLF-5 3433222d en-us print
Response pressure and indi-
cation range respectively
VM2C.x=2bar -10%
VM3C.x=3bar -10%
VM5C.x=5bar -10%
Permissible operating over-
pressure
≤210bar
Permitted temperature range -30…+100°C
Connector threads G½
Installation space required According to HN28-22
Maximum tightening torque 33Nm
Switching type N/C or N/O
(change-over contacts)
Maximum switching voltage 230V
Max. switching voltage at re-
sistive load
60W
100VAAC
Switching capacity ohmic 3A@24VDC
ohmic 0.03to5A@230VAC
Electrical connection Male connection M20
Female connector to
DINEN175301-803
Protection class in accordance
with DIN 40050
IP65 (only if the connector is
wired and fitted correctly)
Tab.14: Differential pressure indicator, electrical VMxC.x
