3.6.2.1 OLF-5/15-S…BM components
The filter unit has the following components:
Fig.9: OLF-5/15-S…BM components
Item Description
IN Fluid inlet
OUT Fluid outlet
DRAIN Draining/draining fluid
1.2 Clogging indicator
2.0 Electric motor
2.1 Ventilator hood
2.3 Terminal box
2.4 Mounting base/electric motor base
3.0 Filter bowl
3.2 Housing clamp
