HYDAC FILTER SYSTEMS OLF-5 Series - Fig. 14 Assembly with a Foot on Electric Motor

HYDAC FILTER SYSTEMS GMBH Mounting/installing | 5
MoWa OLF-5 3433222d en-us print 45 / 100
Fig.14: Assembly with a foot on electric motor
The dimensions, connections and circuit diagrams for the re-
spective version can be found in the "Annex" chapter.
If the oil level in the hydraulic system is higher than
the filter housing, install additional shut-off devices
at the inlet (IN)/outlet (OUT). These shut-off devices
guarantee that the filter element change will be fast
and clean.
1
2
3
4
5
6
7
8
A
