HYDAC FILTER SYSTEMS OLF-5 Series - Components OLF-5-S; Fig. 7 OLF-5-S

3 | Filter unit/filter housing over-view HYDAC FILTER SYSTEMS GMBH
34 / 100 MoWa OLF-5 3433222d en-us print
3.6.1.1 Components OLF-5-S…
The filter unit has the following components:
Fig.7: OLF-5-S… components
Pos. Description
IN Fluid inlet
OUT Fluid outlet
DRAIN Draining/draining fluid
1.2 Clogging indicator
2 Electric motor
2.1 Ventilator hood
2.3 Terminal box
2.4 Mounting base/electric motor base
3 Filter bowl
3.2 Housing clamp
