NOTICE
Pressure port / Outlet OUT closed
The filter unit/filter housing will be damaged/destroyed
u
Make sure that the pressure port is always open during
operation.
OLF-5/4 /
OLF-10/4
In case of the filter unit OLF-5/4 / OLF-10/4, observe:
If the pump is not pre-filled and has an operating viscosity
>200mm²/s, then the unit reaches the maximum flow rate of
4l/min only after ≈10minutes.
