Hydrafeed MSV 80 - Page 191

188
1
3
2
4
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
T04203-000X
S80
Zero point set
1 : 2
2015/6/1
A
Q'ty
Part Number
Item
1
P+F[NBB2-12GM40-E0-5M]
1
1
T14817-000X
2
2Hex socket cap screws-SW Set[M8x1.25x25L]3
2Hex socket cap screws-S Set[M8x1.25x35L]
4
1Hex socket cap screws-S Set[M8x1.25x40L]
5
2
Washer[8.4x16x3.0]
6
2
3
1
5
64
