Hydrafeed MSV 80 - Page 204

201
1
3
2
4
5
678
A
B
C
D
E
F
G
H
Q'ty
Part Number
Item
1
T15101-000X
1
2
T15102-000X
2
2
T15108-000X
3
1
Hex socket cap screws-SW Set[M8x1.25x25L]
4
2
Hex socket cap screws-S Set[M6x1.0x30L]5
2
Washer[6x19x1.5]
6
1
Pin[4x25L]
7
2
Set Screw[M12x1.75x10L]
8
2
Radial Bearing[688ZZ]-NSK
9
1
38
6
4
9
2
7
5
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
T05102-000X
S80
Feeding roller set
1 : 2
2015/2/11
A
