Hydrafeed MSV 80 - Page 205

202
1
3
2
4
5
678
A
B
C
D
E
F
G
H
Q'ty
Part Number
Item
1
T15105-000X
1
1
T15106-000X
2
1
T15116-000X
3
1Hex socket cap screws-S Set[M6x1.0x20L]4
2
Hex socket cap screws-S Set[M6x1.0x25L]5
2Hex socket cap screws-S Set[M6x1.0x30L]
6
1
Hex socket cap screws-S Set[M8x1.25x30L]
7
1
Nut[M8x1.25]
8
2
Washer[6x19x1.5]
9
2
Washer[8.5x23x2.0]
10
3
Set Screw[M6x1.0x12L]
11
1
Set Screw[M8x1.25x30L]
12
9
1 6
7
10
2
10
12
8
11
3 4
5
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
T05103-000X
S80
Short arm set
1 : 3
2015/2/11
A
