Hydrafeed MSV 80 - Page 211

208
1
324
5
678
A
B
C
D
E
F
G
H
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A3
Rolly
T21106-002X
S80
Top Base - 1200
1 :8
2014/9/25
A
Q'ty
Part Number
Item
1T01302-000X1
1
T11103-002X
2
1
T11104-002X
3
2
T11115-000X
4
1
T11116-000X
5
1
T11120-000X
6
1
T11127-002X
7
1
T11128-000X
8
2
T11129-000X
9
3
T11321-000X
10
1
T16101-000X
11
1
T16102-000X
12
1
T21202-002X
13
1
T29103-000X
14
1
Telemecanique[XCS-PA791]
15
2
P+F [M100/MV100-RT]
16
12
Hex Socket Pan Head Screw-SW Set[M6x1.0x16L]
17
2Hex socket cap screws-SW Set[M4x0.7x35L]18
2Hex socket cap screws-SW Set[M4x0.7x8L]19
10Hex socket cap screws-SW Set[M6x1.0x12L]
20
18Hex socket cap screws-SW Set[M6x1.0x16L]21
2Hex socket cap screws-SW Set[M4x0.7x8L]22
4
Hex socket cap screws-S Set[M5x0.8x10L]
23
2Hex socket cap screws-S Set[M6x1.0x16L]24
4
Hex socket cap screws[M3x0.5x8L]
25
3
Nut-S Set[M3x0.5]
26
2
Nut-S Set[M4x0.7]
27
16
Blind Rivet Nut[M6x1.0]
28
3
Hex socket flat head screw[M3x0.5x8L]
29
2
Hex cap nut-SW Set[M6x10]
30
21
263
10 29
17 1
21
14
17
8
9
2316
19
4
302818
156
27
7
12 11
25
2
22
24
20
21
5
16
13
