Hydrafeed MSV 80 - Page 218

215
1
3
2
4
5
678
A
B
C
D
E
F
G
H
Q'ty
Part Number
Item
1T11131-000X1
1
T13103-000X
2
1
T13104-000X
3
1
T13109-000X
4
1
T13110-000X
5
1
Hex socket cap screws-S Set[M10x1.5x30L]
6
2
Hex socket cap screws[M16x2.0x30L]
7
2
Hex socket cap screws[M6x1.0x25L]
8
1
Nut-SW Set[M8x1.25]
9
3
Nut[M16x2.0]
10
2
Hex head cap screws-SW Set[M16x2.0x30L]
11
1
Washer[10.5x26x2.0]
12
1
Washer[16.5x40x3.0]
13
13
10
2
12
6
5
3
4
8
1
7
11
10
9
Model
Weight
Quantity
Unit：mm
Name
Date
Revision
Part No.
Draw
Material
Scale
Page
1
1 / 1
>400....±0.8
120-400....±0.5
30-120....±0.3
6-30....±0.2
3 - 6 . . . .
±
0 . 1
< 3 . . . .
±
0 . 1
G e n e r a l
T o l e r a n c e
A4
Rolly
T01101-000X
S80
Left stand
1 :5
2015/2/11
A
